Features:
- Do not need to shut down the pipe flow when installing the transducers
- It is suitable for pipe sizes ranging from 65 to 4000mm
- For dirty liquids, a certain amount of air bubbles or suspended solids shall be contained
- Excellent low flow rate measurement ability, low to 0.05m/s
- A wide range of flow measurement, high flow rate can reach 12m/s
- High-temperature transducer is suitable to liquids of -35℃ ~ 150℃
- User-friendly configuration
- 4-20mA, Relay Totalizer and Relay Alarm outputs
- Accuracy: 2.0% Calibrated span
See the full Brochure / Datasheet for full specifications.
